Product Description

STRUCTURE

1. Each printing group of the machine is furnished with a synchronous belt drive and a robust hard gear face gear box, incorporating a high-precision planetary gear oven that enables a 360º plate adjustment. This setup effectively propels the press printing roller.

2. The machine offers ample space for the material to traverse post-printing, facilitating straightforward ink drying and delivering exceptional outcomes.

CONTROL PART

1. Main motor frequency control

2. Reduce motor separate

PRINTING PART

1. Pneumatic lifting and lowing printing plate cylinders auto lifting plate cylinder when the machine is stopped. After that can run ink automatically. When the machine is opening,it will make alarm to start the auto lowering plate printing cylinder.

2. Inking with ceramic anilox chambered doctor blade ink pump circulation

3. High precision planetary gear oven 360°circulation longitudinal register

4. ±0.2mm transverse register

5. Adjust inking press and printing pressure press by manual

DRYING PART

1. Adopt with external heating pipe, temperature display, electric current control,centrifugal blower bring the wind

Technical Parameters

TYPE	LYT6-800	LYT6-1000	LYT6-1200	LYT6-1300
Max. Printing material width	800mm	1000mm	1200mm	1300mm
Max. Printing width	760mm	960mm	1160mm	1260mm
Printing length range	230-800mm	230-800mm	230-800mm	230-800mm
Printing speed	5-100m∕min	5-100m∕min	5-100m∕min	5-100m∕min
Register precision	≤±0.20mm	≤±0.20mm	≤±0.20mm	≤±0.20mm
Thickness of plate (including the thickness of double sides glue)	Can be customized according to customer requirements. Default plate thickness 2.28MM + double-sided tape 0.38MM

Accessories description

No.	Name	Origin
1	Main motor	CHINA
2	Inverter	Inovance
3	Inking reducer	CHINA
4	All of the low voltage control switch	Schneider
6	Main bearing	taiwan
7	Roller bearing	CHINA
