Product Description

STRUCTURE

1. The machine is equipped with synchronous belt drive and a hard gear face gear box. The gear box utilizes synchronous belt drive for each printing group, with a high-precision planetary gear oven (360º plate adjustment) driving the press printing roller.

2. After printing, the ample material space allows for easy ink drying, resulting in better outcomes.

CONTROL PART

1. Main motor frequency control

2. Reduce motor separate

PRINTING PART

1. Pneumatic lifting and lowing printing plate cylinders auto lifting plate cylinder when the machine is stopped. After that can run ink automatically. When the machine is opening,it will make alarm to start the auto lowering plate printing cylinder.

2. Inking with ceramic anilox chambered doctor blade ,ink pump circulation

3. High precision planetary gear oven 360°circulation longitudinal register

4. ±0.2mm transverse register

5. Adjust inking press and printing pressure press by manual

DRYING PART

1. Equipped with external heating pipes, temperature display, electric current control, and a centrifugal blower to provide air circulation.

Technical Parameters

TYPE	LYT4-800	LYT4-1000	LYT4-1200	LYT4-1300	LYT4-1400B
Max. Printing material width	800mm	1000mm	1200mm	1300mm	1400MM
Max. Printing width	760mm	960mm	1160mm	1260mm	1360MM
Printing length range	230-800mm	230-800mm	230-800mm	230-800mm	280-800mm
Printing speed	5-100m∕min	5-100m∕min	5-100m∕min	5-100m∕min	5-100m∕min
Register precision	≤±0.20mm	≤±0.20mm	≤±0.20mm	≤±0.20mm	≤±0.20mm
Dimension	3600X1900X2200	3600X2100X2200	3600X2180X2200	3600X2270X2200	3600X2370X2200
Weight (approx.)	2.4T	2.7T	2.8T	3T	3.2T
Power	9KW	9KW	12KW	12KW	12KW

Accessories description

NO	Name	Origin
1	Main motor	CHINA
2	Inverter	Inovance
3	Inking reducer	CHINA
4	All of the low voltage control switch	Schneider
6	Main bearing	taiwan
7	Roller bearing	CHINA
