Product Description

Properties And Uses

1. The machine is equipped with a synchronous belt drive and a hard gear face gear box for each printing group, featuring a high-precision planetary gear oven that allows for 360º plate adjustment. This arrangement drives the press printing roller effectively.

2. The machine provides a spacious area for the material to run after printing, enabling easy ink drying and yielding superior results.

CONTROL PART

1. Main motor frequency control

2. Reduce motor separate

PRINTING PART

1. Pneumatic lifting and lowing printing plate cylinders auto lifting plate cylinder when the machine is stopped. After that can run ink automatically. When the machine is opening,it will make alarm to start the auto lowering plate printing cylinder.

2. Inking with ceramic anilox chambered doctor blade ,ink pump circulation

3. High precision planetary gear oven 360°circulation longitudinal register

4. ±0.2mm transverse register

5. Adjust inking press and printing pressure press by manual

DRYING PART

1. Utilizing external heating pipes, temperature display, electric current control, and a centrifugal blower to facilitate air circulation for drying purposes.

Technical Parameters

TYPE	LYT2-800	LYT2-1000	LYT2-1200	LYT2-1300	LYT2-1400B
Max. Printing material width	800mm	1000mm	1200mm	1300mm	1400MM
Max. Printing width	760mm	960mm	1160mm	1260mm	1360MM
Printing length range	230-800mm	230-800mm	230-800mm	230-800mm	280-800mm
Printing speed	5-100m∕min	5-100m∕min	5-100m∕min	5-100m∕min	5-100m∕min
Register precision	≤±0.20mm	≤±0.20mm	≤±0.20mm	≤±0.20mm	≤±0.20mm
Dimension	2240x1900x2200	2240X2100X2200	2240X2170X2200	2240X2270X2200	2240X2370X2200
Weight (approx.)	1.8T	2T	2.3T	2.5T	2.7T
Power	7KW	7KW	9KW	9KW	11KW

Accessories description

NO	Name	Origin
1	Main motor	CHINA
2	Inverter	Inovance
3	Inking reducer	CHINA
4	All of the low voltage control switch	Schneider
6	Main bearing	taiwan
7	Roller bearing	CHINA
